Description
M10 is an electronic measuring plug, with or without self-centered nosepiece, for the inspection on a single diameter within range of 13-140mm, divided into:
- type A for range 13-21 mm
- type B for range 21-45 mm
- type C for range 45-140 mm
M10 was developed for easy integration on a transfer machines, particularly to measure cylinder block bores and connecting rod bores.
A simple design with high quality components to assure the best performances over time, under harsh conditions of machine tools.
The system can be equipped with a recoiling system for safety operations, in case of improper positioning of the part.
The plug can be fitted with an air-blow-off system for part cleaning before inspection.
The measurement is always performed using Marposs HBT transducer technology; a special electronic buffer is applied to a plug-in order to switch the output signals from HBT (summed or separated) to LVDT (summed or separated as well).
Depending on the material of the part being inspected, it is possible to use widia with a dlc and diamond contacts.
